A cut-off machine with the world’s first electronically controlled fuel-injection system that increases power, not weight when operating 14” wheels. STIHL offers another industry first with the TS 500i STIHL Cutquik® cut-off machine. Featuring the handheld outdoor power equipment industry’s first electronically controlled fuel-injection system, the TS 500i increases power by 17% and cutting speed by 15%, as compared to the STIHL TS 420. Powerful, lightweight and well-balanced, the STIHL TS 500i is designed for superior handling during the toughest jobs. The low-emission engine provides optimal torque throughout the RPM range and eliminates the need for a choke, simplifying the starting procedure. The standard electronic water control feature allows for easy and efficient water flow adjustment while cutting. The X2 air filtration system is virtually maintenance-free and maintains an incredible 99.96% cleaning efficiency.
| STIHL TS 500i STIHL Cutquik® Specifications | |
| DISPLACEMENT | 72.2 cc (4.41 cu. in.) |
| ENGINE POWER | 3.9 kW (5.2 bhp) |
| FUEL TANK CAPACITY | 725 cc (24.5 oz.) |
| ENGINE SPEED | 9,000 rpm (Elec. Gov.) |
| MAXIMUM SPINDLE SPEED | 5,350 rpm |
| ARBOR SIZE | 20 mm |
| MAXIMUM WHEEL SIZE | 350 mm (14 in.) |
| MAXIMUM CUTTING DEPTH | 125 mm (4.9 in.) |
| POWER SOURCE | Gas |
| WEIGHT | 10.2 kg (22.5 lbs.) |
